AEE03A18-LS Artesyn 15 Watt Isolated DC-DC Converters (Low-Input)

The AEE series of 15 watt low-input isolated DC-DC converters features an ultra wide 4:1 input voltage range of 9–36 Vdc and is designed primarily for use with nominal 12 V or 24 V supplies. There is a choice of four single output models, offering voltages of 3.3 V, 5 V, 12 V or 15 V, and three dual output models offering +5/-5 V, +12/-12 V or +15/-15 V. The converters are fully encapsulated in a compact 1 x 2 inch (25.4 x 50.8 mm) metal case and have a height of just 0.44 inch (11.3 mm). They are ideal for ruggedized applications involving harsh environments.

Особенности

• 4:1 Input Range
• Single or Dual Output
• MTBF: > 1 M Hours
• Through Hole Termination
• RoHS 6/6 Compliant
• UL Approved

Технические характеристики

• Total Max Power:
  15 W
• Total Max Current:
  4 A
• Input Voltage:
  9 V to 75 V
• Output Voltage:
  -15 V to 15 V
• Outputs:
  Single, Dual
• Size (L x W x H):
  2.000" x 1.000" x 0.440"
• Warranty:
  2 years
• Operating Temperature:
  -40°C to +71°C
