ASA03G48-LS Artesyn 10 Watt Isolated DC-DC Converters (48 Vin)

This version of the ASA series of 10 watt isolated DC-DC converters features a wide 2:1 input voltage range of 36–75 Vdc and is primarily designed for use with nominal 48 V supplies. There is a choice of four single output models, offering voltages of 2.5 V, 3.3 V, 5 V, or 12 V. The converters are fully encapsulated in a compact 1.25 x 0.8 inch (31.7 x 20.3 mm) metal case and have a height of just 0.4 inch (10.2 mm). They are ideal for ruggedized applications involving harsh environments.

Особенности

• Encapsulated
• 2:1 input range
• 1.25" x 0.8" DIP package
• 1500 Vdc I/O isolation
• Single output
• UL Approved

Технические характеристики

• Total Max Power:
  10 W
• Total Max Current:
  3 A
• Input Voltage:
  18 V to 75 V
• Output Voltage:
  2.5 V to 12 V
• Outputs:
  Single
• Size (L x W x H):
  1.250" x 0.800" x 0.400"
• Warranty:
  2 years
• Operating Temperature:
  -40°C to +60°C
