Тепловизор Guide P120V Pocket

Pocket-sized Thermal Camera

P120V Pocket-sized Thermal Camera designed for electrical equipment maintenance and building inspection, which can fast detect the potential problems, report repair data and share images by Wi-Fi. It is a truly handy thermal camera that fits in your pockets for fast and accurate thermal inspections anytime. P120V featured with 3.5-inch LCD touchscreen for simple operation, and support picture-in-picture, smooth zoom, max and min temperature alarm, Cloud Service and more.

Технические характеристики

Imaging and optics

Detector type: VOx

Infrared resolution: 120 × 90@17μm

Wavelength range: 7.5 to 14μm

Focal length: 2.28 mm

Field of view: 50° × 38°

IFOV: 7.46mrad

Minimum object distance: 0.5 m

D:S: 130:1

NETD: ≤60 mK

Infrared frame rate: 15 Hz / 9 Hz

Focusing mode: Focus-free

Digital zoom: 1.1x to 8x

Measurement and analysis

Measurement range: Support auto-switching: -20°C to 150°C, 100°C to 400°C

Measurement accuracy: ±2°C or ±2%, whichever is greater

Analyzed target: Spot × 1, Area × 1

Tracking / Alarm: Full screen maximum/minimum temperature tracking; The maximum or minimum temperature tracking of analyzed target; full screen temperature threshold alarm (image)

Temperature measuring parameters: Emissivity, reflected temperature, target distance
